Fire Testing

HBK 919

Horizontal Burner Box

Highlights

Fire Testing System for determining the reaction to fire of materials used for vehicle interiors when exposed to a single flame source, in accordance with ISO 3795, DIN 75200, FMVSS 302, GB 8410, IS 15061, CMVSS 302, U.T.A.C. 18-502, FAR 25.853

Well thought-out details along with the use of high-quality materials guarantee the HBK 919 system an extended product life while reducing wear and tear, lessening the need for cleaning and maintenance, increasing safety and greatly simplifying day-to-day work at the lab. In addition, the HBK 919 complies with the different vehicle manufacturers’ works standards.

  • Sample holder for tests of interior fitting materials and components in accordance with car manufacturers' works standards
  • Main gas valve positioned on the left side of the device for easy accessibility
  • Adjustable pressure reducer for propane bottle, additional gas pressure reducer mounted directly on device
  • Precise sample holder guidance for fast and easy switching of samples
  • Burner box with fireproof glazing at the front, door with Bunsen burner at the side, pressure-reducing valve at the rear and top cover with handle (with optional thermometer mount); all parts made of stainless steel for long-term maintenance-free use
  • Sample holder without support wires; additional sample holders available as options
  • Stainless steel drip tray for collecting droplets/particles
  • Gauges for flame height
  • Digital stop watch for timing in accordance with standard

Specifications

Measurement method

Determining the reaction to fire of materials used for vehicle interiors in accordance

with ISO 3795, DIN 75200, FMVSS 302, GB 8410, IS 15061, CMVSS 302,

U.T.A.C. 18-502, ECE R 118 Attachment 6, FAR 25.853 (horizontal, aircraft

interiors)

Sample holder1x sample holder of stainless steel without support wires
BurnerBunsen burner
Burner gas

Propane gas: ≥95% purity, gas pressure: 4.0 bar (Gas to be provided by the user),

adjustable gas pressure reducer (50 mbar) included
